MAX BMW is your #1 Source for BMW Airhead Parts!

Click below to order, or e-mail Francis Jordan at francis@maxbmw.com or call 203-740-1270 ext. 1219.

Slash 5 Revive!

OEM Bench Seat

This is a second series /6 seat; it has cross-ribbed pleats (side to side). Appears to have more foam padding (in the front) than the original. Vinyl covered. It fits all /5 LWB and /6 models (except R90S). It also retrofits models that have first generation seats with long ribbed pleats (front to back). Chrome grab rail included. The rear hinge is sold separately; the front hinge is included and riveted on at the factory.

Fits the following BMW Models:
R50/5 - R75/5 post 1972; R60/6 - R90/6

BENCH SEAT - LONG WHEEL BASE
Part Number: 52531233960
PRICE: $492.55 [CLICK HERE TO BUY]

Albert Headlight Mirrors

Threads on mirror are M8x1.25x50mm. Chrome nut on assembly allows you to adjust the depth that mirror is installed at. Albert Mirrors fit the classic, vintage BMW models from 1950 through 1973.

Fits the following BMW Models:
R60, R60/2, R60US, R67, R67/2/3, R68, R69, R69S, R69US
Consult with parts associate to see if it can fit yours.

ALBERT HEADLIGHT MIRRORS - PAIR
Part Number: ACC007
PRICE: $170 [CLICK HERE TO BUY]

Headlight Protection Bow

Fits the following BMW Models:
Fits models R24 - /5

CHROME HEADLIGHT PROTECTION RING
Part Number: 71609024029
PRICE: $39.95 [CLICK HERE TO BUY]

EnduraSpark Ignition System

The Moto Electrics EnDuraSpark Electronic Ignition is an electronic Hall Effect trigger and electronic ignition advance module based on Sachse Electroniks (Germany) components. It replaces the stock under-performing BMW ignition points, condenser, mechanical advance unit and on later models, the electronic ignition control unit and bean can trigger unit. This ignition replaces the ignition systems on all 1970-1995 BMW motorcycles. It is configurable for both single-plugged and dualplugged engines. It is the last improvement ever needed on an Airhead ignition!

Modern electronics technology updates the BMW R Airhead under-performing Bosch ignition system.
The critically important ignition timing is maintained with a crank-mounted trigger rotating past a micro-size hall effect sensor.
Dyno developed advance curves for BMW single- and also dual-spark system can be chosen during installation.
The EnDuraSpark Ignition Module mounts in the old voltage regulator location, away from heat and vibration.
The original Bosch ignition system can be left in place.

When installing this upgrade, it must be used in conjunction with the EnDuraLast Charging System Kit. See PDF thumbnail for important information on this item.

Fits the following BMW Models:
R75/5 ECE - Also available for other models

ENDURASPARK IGNITION SYSTEM
Part Number: EDL-IGNS
PRICE: $379 [CLICK HERE TO BUY]

ND 8 Tooth Starter

Starter motor is made by Nippondenso, originally for use in Toyota trucks and mated to a new casting and drive gear to fit the BMW engine. The high torque planetary gear design DOES NOT use glued-in magnets for the motor fields. Robust construction and wire-coil fields insure long service and can be rebuilt. At 6 lbs., it's approximately half of a Bosch's weight, and draws 80 amps of battery current, compared to the 120 amp draw common to Bosch.

Drop-in replacement requires no modifications or rewiring. The starter ships with new mounting bolts and nuts. One year warranty. This starter is good for 1970-76 /5, /6, and R90S models that have an 8 tooth drive gear! Very well suited for use on high-compression or performance-modified engines.

Available for the following BMW Models:
R50/5, R60/5, R60/6, R75/5, R75/6, R90/6, R90S

NIPPONDENSO EL STARTER - 8 TOOTH
Part Number: ND8T
PRICE: $395 [CLICK HERE TO BUY]

EnduraLast Charging System Kit

THE ultimate upgrade for your BMW Airhead's charging system is this 450w alternator kit

Updated Design with fewer Components
One Kit fits ALL Airheads - no need to know the stator size
Plug and Play Harness simplifies Installation
Detailed Installation Guide-
Easy Installation
Brushless
Proven International application over many years

The Kit includes all the components to replace your under-performing 240w BOSCH charging system. Featuring a Permanent Magnet Rotor which eliminates the brushes and potential rotor failure. The Hi-Output Stator produces significant AC voltage at lower RPM's not possible with the original system. The combined Voltage Regulator / Rectifier eliminates the two components most vulnerable to failure on the BOSCH charging system, namely the diode board and the voltage regulator. In addition the kit includes a Rotor Removal Tool, a new timing cover Oil Seal and a Caliper for accurate measurements. NOTE: The /5 Airhead models require a starter relay modification. Please review the Installation Guide for details.

Fits the following BMW Models:
All BMW Airheads.

ENDURALAST CHARGING SYSTEM KIT
Part Number: EDL4
PRICE: $539.99 [CLICK HERE TO BUY]

97 MM Power Kit

More power and torque for 1970-75 R75, R80, R90 models up to 09/1975 (models with only 97mm crank case opening in the crankcase for cylinder base). Includes new Nikasil cylinders, 1000cc pistons, wrist pins, rings, and circlips. No need to change original connecting rods. Bolt on and go! Used and raced by Team MAX BMW. NOTE: Do not forget top end gaskets!

Fits the following BMW Models:
1970-75 R75, R80, R90 models up to 09/1975

AIRHEAD 97 MM POWER KIT
Part Number: 1100072
PRICE: $1249 [CLICK HERE TO BUY]
